Hydrophilic Aluminum/Aluminium Foil for Air Conditioner Evaporator Condenser Coil
Product Details:
Place of Origin: | China |
Brand Name: | Xienuo Aluminum |
Model Number: | 1235 3003 3004 8011 |
Payment & Shipping Terms:
Minimum Order Quantity: | 5 ton |
---|---|
Packaging Details: | Film + foam + paper packaging or Film + foam + wooden box packaging for Aluminum Foil Manufacturer aluminumfoil jumbo roll aluminum foil rolls |
Delivery Time: | 15-25 days |
Payment Terms: | L/C,T/T |
Supply Ability: | 500,000 tons per year |
Detail Information |
|||
Grade: | 1235 8011 | Temper: | Soft |
---|---|---|---|
Width: | 10mm-2550mm,25-130mm,21-1600mm,1000-1250mm,16-2600 | Thickness: | 0.009-0.2mm |
Surface: | Smooth,Clean,smooth/embossed,Powder Coated,Mill Finsh | Alloy: | 1050/1060/1100/3003/3004/5005/5052/5083/3005/8011,1050 1060 1061,A3003,3003 1100 8011,Is Alloy |
Material: | 1050/1060/1070/1100/3003/5052/5083/6061/6063,Aluminum Material,aluminum Coil,Anodized Aluminum Trim Cap,3003 | Standard: | ASTM AISI JIS DIN GB,DIN,ASTM,SGS,GB/T3880-2006 |
Package: | Film + Foam + Paper Packaging Or Film + Foam + Wooden Box Packaging For Aluminum Foil Manufacturer Aluminumfoil Jumbo Roll Aluminum Foil Rolls | Use: | Food |
Product Description
What is Hydrophilic Aluminum Foil?
Hydrophilic aluminum fin stock foil is widely used in residential air-conditioning units, commercial freezers,automobile air conditioning units and water tanks .
Technology Standard For Hydrophlic Aluminium Fin Stock
Alloy |
Temper |
Mechanical performance under room temperature | ||
Tensile (Mpa) | Elongation (e%) | Erichson (IE,mm) | ||
1100 1200 8011 |
O | 80~110 | ≥ 20 | ≥ 6.0 |
H22 | 100~135 | ≥ 16 | ≥ 5.5 | |
H24 | 115~145 | ≥ 12 | ≥ 5.0 | |
H26 | 125~160 | ≥ 8 | ≥ 4.0 | |
H18 | ≥ 160 | ≥ 1 | - | |
Re: if customers have special requirements, please idicate them in purchase order. |
Alloy | 8011, 3102, 1100, 3003, as per customer's demands |
Temper | O, H18, H22, H24, others |
Thickness | 0.06-0.2mm |
MOQ | 3 Tons |
Package | Standard Export wooden Case/Pallet |
Delivery Time | 30 working days after received your down payment |
Supply Ability | 50,000 mt per year |
Characteristics | Strong anti-corrosion |
Salt spray test | 1)epoxy coated aluminum foil:500 Hours,class 8 in PH<7; |
2)hydrophilic aluminum foil:500 Hours,class 9.5 in PH=7. |
Remark: Specific requirement of alloy, temper or specification can be discussed at your request.
Application of Aluminum Foil
1, Transportation (aircraft,high-speed train, ships, cars, etc.) |
2, Construction (walls, ceiling, platforms, roofs,aluminum glass spacer, etc.) |
3, Digital home appliances (refrigerators, air conditioners, freezers, computers, etc.) |
4, Electronic (circuit board pads,capacitors, etc.) |
5, Home (cooking utensils,household foil,lunch boxes, etc.) |
6, Print (PS sheet, CTP sheet, etc.) |
7, Other (tape,pipe packaging,anti-slip pedals, etc.) |
Xienuo Product Process Flow
Xienuo Advantages
1. we have rich experience in this industry in China;
2. Good reputation in the production of aluminium/aluminum plate areas;
3. We start our productions from aluminum ingot,so we can control the quality as well;
4. We have our own development department for new material research;
5. Good experience and cooperation with big clients in the world;
6. High performance cost ratio;
7. Fast delivery time;
8. Customized orders available;
9. Good communication skills, and good service and understandings for customers.
Xienuo International Exhibition
